PA-GF (MJF)

MJF-PA-GF is a thermoplastic filled to 40% with glass beads.

Properties

Material features

  • Density [g/cm3] 1.3
  • Tensile strength [Mpa] 30
  • E-modul [GPa] 2.9
  • Heat deflection temp @0.45MPA [°C] 170
  • Heat deflection temp @1.81MPA [°C] 113
  • Elongation at break [%] 10

Advantages

  • Optimum mechanical properties
  • With 70% a high recycling rate
  • Complies with UL-94 fire protection standard as well as UL-746A standard for plastics
  • Enables components in the best designs

MJF-PA-GF is a thermoplastic filled to 40% with glass beads. Optimum mechanical properties are as much a benefit of this material as a high recycling rate of around 70%. In this way, MJF-PA-GF makes it possible to significantly reduce the unit costs of production.
